Serial#  N3*****

Manufacture Date: 12/17/1993

Model Name: American Standard Stratocaster®
Model Number: 010-7400-(Color#) and 010-7402-(Color#)
Series: American Standard Series
Body: Alder (Swamp Ash on Natural, 721 and White Blonde, 701)
Neck: Maple
Fingerboard: Rosewood (010-7400) or Maple (010-7402), (9.5” Radius/241 mm)
No. of Frets: 22 Medium Jumbo Frets
Scale Length: 25.5” (648 mm)
Width @ Nut: 1.6875” (43 mm)

Hardware: Chrome
Machine Heads: Fender/Schaller Deluxe Cast/Sealed
Bridge: American Standard
Pickguard: 3-Ply White
Pickups: 3 American Standard Strat Single Coils
Pickup Switching: 5-Position Blade:
Position 1. Bridge Pickup
Position 2. Bridge and Middle Pickup
Position 3. Middle Pickup
Position 4. Middle and Neck Pickup
Position 5. Neck Pickup
Controls: Master Volume, Tone (Neck), TBX Tone (Mid, Bridge),
Changed to Master Volume, Tone 1. (Neck Pickup), Tone 2. New Delta-ToneTM system includes high output bridge pickup and special “no-load” tone control (Middle and Bridge Pickups) in late 1999
Colors: 1990 through 2000
... список кодов ...
(775) Midnight Wine,  (конкретно мой был выделен)
...
(Polyurethane Finish)
Strings: Fender Super Bullet 3250L’s (.009 to .042) Nickel Plated Steel  pn#073-3250-003

Source: U.S.
Accessories: Molded Case
U.S. MSRP: $1,049.99  (With Swamp Ash Body $1,199.99)
INTRODUCED: 1/1987
DISCONTINUED: 6/2000
WRENCH SIZES: Truss Rod Wrench #023811 (1/8” Hex)
Saddle Height Adjustment Wrench #018531 (.050 Hex)
COMMENTS: Replaced by the new "American Stratocaster" 6/2000,
Changed from TBX to Delta-Tone in late 1999,
In 1994 American Standard Stratocasters had a 4-Color Medallion on the Front of the Headstock and an Engraved Neckplate Commemorating the 40th Anniversary of the Stratocaster
NOTICE: Product Prices, Features, Specifications and Availability Are Subject To Change Without Notice
